108
JACKS AND PLUGS
EXTENSION JACKS AND 1/4" SPEAKER JACKS PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
1/4" EXTENSION JACKS (IN-LINE)
TWO-CONDUCTOR PART NUMBERS
Part
Mating
Plug
Number
80
Description
Black handle; screw terminals
250
1
80
120
121, 131
88
Black handle; solder lugs
250
Extension Jax ? jacks are connected to the end of a cable.
2- and 3-conductor jacks mate with standard commercial
phone plugs, and have a sturdy cable clamp strain relief,
120
121
128
Shielded handle; screw terminals
Shielded handle; solder lugs; cable clamp
Shielded handle; solder lugs
250
250
250
knurled shielded or molded black plastic handles, and a
screw type solder terminal. All internal parts are interlocked.
THREE-CONDUCTOR PART NUMBERS
Note: See locking phone plugs section.
Part
Mating
Plug
SPECIFICATIONS
MATERIAL
Body, Sleeve and Shielded Handle: Nickel-plated
copper alloy.
Plastic Handles: Molded black thermoplastic.
Springs: Special copper alloy.
Bushing and Flange: Plated copper alloy.
Insulation: Thermoplastic.
Number
131
830
S830
838
1230
1238
Description
Shielded handle; solder lugs
Black handle; screw terminals
Similar to No. 830 except, .21" I.D. sleeve
Black handle; solder lugs
Shielded handle; screw terminals
Shielded handle; solder lugs
267
267
480
267
267
267
1
Clamp Terminals: Tin-plated copper alloy.
121, 131
1/4" SPEAKER JACKS
High power 2-conductor speaker jack carries 15A (continuous)
audio speaker current levels. Jack Number Z15J has positive
detent for plug retention. Terminations are solder lug; wires
accepted are up to 10 AWG. Red housing indicates high current
rating. Recommended mating plugs: 70, 184, 187 series.
SPECIFICATIONS
Housing: Glass reinforced thermoplastic, UL 94V-O.
Tip Spring and Ground Terminals: Copper alloy.
Bushing and Hardware: Nickel-plated copper alloy
(hardware supplied).
Heat Rise: 30°C with 15 A continuous carry.
Life: 10,000 (minimum) with proper plug.
1. Other mating plugs are available.
Z15J
Z15J
Part Number
Z15J
Description
High power speaker jack
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
